Komatsu SAA6D114E-3 User Manual

10 Structure, function and maintenance standard SEN00176-02
114E-3 Series
7
Lubricating oil system 1
General Information
1. Gerotor lubricating oil pump
2. Lubricating oil cooler
3. To lubricating oil pan
4. Full flow lubricating oil filter
5. Filter bypass valve
6. From lubricating oil filter
1. From lubricating oil cooler
2. Main lubricating oil rifle
3. To camshaft
4. To piston cooling nozzle
5. From main lubricating oil rifle
6. To connecting rod bearing
Lubricating oil cooler flow
Lubrication for power components
