Komatsu SAA6D114E-3 User Manual

10 Structure, function and maintenance standard SEN00176-02
114E-3 Series
21
Unit: mm
No. Check item Criteria Remedy
1
Inside diameter of cylinder liner 114.000 – 114.040
Replace cylinder
liner
Roundness of cylinder liner Repair limit: 0.04
Taper of cylinder liner Repair limit: 0.04
2 Protrusion of cylinder liner 0.026 – 0.122
Replace cylinder
liner or cylinder
block
3 Outside diameter of cylinder liner 130.938 – 13.0958
Replace cylinder
liner
4
Inside diameter of cylinder liner bore in
cylinder block
130.900 – 13.0950
Replace cylinder
liner or cylinder
block
5
Clearance between cylinder liner and
cylinder block
Min. 0.229
