KONE Maintenance Method
MX10 / MX20 MCP Procedures - ASME A17.1-2013 / CSA B44-13
© 2014 KONE Corporation PSK8-604-MX10/MX20
All rights reserved.
46 (-) 2014-12-15
Procedure Note
1. Push and pull the pulley in the axial direction,
use your hand.
2. Check that the pulley does not move in the
axial direction (No free play).
If there is axial free play the governor must be
replaced.
Wear of the rope groove:
OL100: D < 12.5 mm
OL120: D < 16.0 mm
