3.2 Maintenance Procedures in the Machine Room
8.6.1.2.2 (a): Wiring diagrams
Procedure Note
Check to ensure legible, up-to-date wiring
diagrams are available on-site.
Notify your supervisor if complete wiring
diagrams are not available.
8.6.1.2.2 (b): SIL rated devices
Procedure Note
If SIL rated E/E/PES electrical protective
devices are installed:
• Ensure wiring diagrams document the SIL
rated devices.
• Ensure the SIL rated devices are marked
accordingly.
• Ensure maintenance, repair and testing
documentation for the devices is available
on-site.
If software is integral to the SIL rated device,
check to ensure the software version is as noted
in the manufacturer’s technical documentation.
• Upgrade the software if necessary.
• For KONE drive units the software
versions should be as noted below:
− KDM SW version 101.00, and later
− DCBG SW version 2.64, and later
8.6.1.5 (See 8.9): Code data plate
Procedure Note
Check to ensure a data plate has been provided
and is maintained for each unit.
• The data plate shall indicate the Code to be
used for inspections and tests
• The Code and edition in effect at time of
installation.
• The data plate shall also indicate the Code
in effect at the time of alteration and
indicate the applicable requirements of 8.7.
• The data plate shall be in plain view,
securely attached to each main line
disconnect or controller.
