KONE Maintenance Method
MX10 / MX20 MCP Procedures - ASME A17.1-2013 / CSA B44-13
© 2014 KONE Corporation PSK8-604-MX10/MX20
All rights reserved.
33 (-) 2014-12-15
Test manual brake release: MX20
Procedure Note
1. Check the brake function by installing the
brake release lever and pulling it to the
brake open position (3).
Any further adjustments must be done
by the cable end nut, not by the center
nut!
2. Ensure that the lever returns to the “brake
closed” position (1) by itself.
NOTE! If brake handle (9) does not return,
check brake cable and aluminum tube for
sharp radii, twists and other blockages.
