I/O Control
Winbond W83627DHG LPC Bus I/O Controller
Peripheral
interfaces
• Eight USB 2.0 ports on I/O area
• Two USB 2.0 ports on internal pinrows
• Two Serial ports (RS232)
• One Parallel port, SPP/EPP/ECP
• Six Serial ATA-300 IDE interfaces
• PS/2 keyboard and mouse ports
LAN
Support
• 2x 10/100/1000Mbits/s LAN using Realtek RTL8111B controllers
• RPL/PXE netboot supported. Wake On LAN (WOL) supported.
BIOS
• Kontron Technology / AMI BIOS (core version)
• Support for Advanced Configuration and Power Interface (ACPI 2.0), Plug and Play
o Suspend To Ram
o Suspend To Disk
o Intel Speed Step
• Secure CMOS/ OEM Setup Defaults
• “Always On” BIOS power setting
• RAID Support (RAID modes 0, 1, 5 and 10) (for Linux O/S only RAID 0 and 1)
Expansion
Capabilities
• PCI Bus routed to PCI slot(s) (PCI Local Bus Specification Revision 2.3)
o KT965/Flex: 2 slots
PCI 2.3, 32 bits, 33 MHz, 5V compliant
o KT965/
ATXP: 6 slots PCI 2.3, 32 bits, 33 MHz, 5V compliant
o KT965/
ATXE: 5 slots PCI 2.3, 32 bits, 33 MHz, 5V compliant
• PCI-Express bus routed to PCI Express slot(s) (PCI Express 1.0a)
o KT965/Flex: 1 slot
PCI-Express x16, 1 slot PCI-Express x4
o KT965/
ATXP: 1 slot PCI-Express x16
o KT965/
ATXE: 1 slot PCI-Express x16, 1 slot PCI-Express x4
• Mini PCI-Express routed to mini PCI-Express connector
Support for Mini PCI-Express modules with no components on backside.
o KT965/Flex: None
o KT965/
ATXP: 1 slot mini PCI-Express x1
o KT965/
ATXE: None
• SMBus routed to FEATURE, PCI slot, PCI Express and mini-PCI Express connectors
• LPC Bus routed to TPM connector
• DDC Bus routed to LVDS and CRT connector
• 8 x GPIOs (General Purpose I/Os) routed to FEATURE connector
Hardware
Monitor
Subsystem
• Smart Fan control system, support Thermal® and Speed® cruise for three onboard
Fan control connectors: FAN_CPU, FAN_SYS and FEATURE
• Three thermal inputs: CPU die temperature, System temperature and External
temperature input routed to FEATURE connector. (Precision +/- 3ºC)
• Voltage monitoring
• Intrusion detect input
• SMI violations (BIOS) on HW monitor not supported. Supported by API (Windows).
Operating
Systems
Support
• Win2000
• WinXP
• Win2003
• WinXP Embedded (limitations may apply)
• Windows Vista
• Linux: Feodora Core 5, Suse 10.01 (limitations may apply)
(continues)
