4.10.4 USB Connector 8/9 (USB8/9)
USB Ports 8 and 9 are available on the I/O frontpanel.
Note
Pull
U/D
Ioh/Iol
Type
Signal
PIN
Signal
Type
Ioh/Iol
Pull
U/D
Note
1 2 3 4
1 - - PWR 5V/SB5V GND PWR - -
/15K 0.25/2 IO USB8- USB8+ IO 0.25/2 /15K
1 2 3 4
1 - - PWR 5V/SB5V GND PWR - -
/15K 0.25/2 IO USB9- USB9+ IO 0.25/2 /15K
Note 1: The 5V supply for the USB devices is on-board fused with a 2.0A reset-able fuse. The supply is
common for the two channels. SB5V is supplied during power down to allow wakeup on USB device activity.
In order to meet the requirements of USB standard, the 5V input supply must be at least 5.00V.
Signal Description
USB8+ USB8-
USB9+ USB9-
Differential pair works as Data/Address/Command Bus.
USB5V 5V supply for external devices. Fused with 2.0A reset-able fuse.
