KT965 Family
KTD-00699-S Public User Manual Date: 2010-04-15 Page 60 of 90
6.4 I/O Map
Address (hex) Size Description
0020- 0021 1 Programmable interrupt controller
0040- 0043 4 System Timer
0060- 0060 1 Standard keyboard
0061- 0061 1 System speaker
0064- 0064 1 Standard keyboard
0070- 0071 2 System CMOS/Real time clock
0170- 01F7 8 Secondary Parallel ATA IDE Channel
01F0- 01F7 8 Primary Parallel ATA IDE Channel
02F8- 02FF 8 Comport 2 / IRDA
0376- 0376 1 Secondary IDE Channel
0378- 037F 8 Printer Port
03B0- 03BB 12 Intel 965 Express Chipset Family
03C0- 03DF 32 Intel 965 Express Chipset Family
03F6- 03F6 1 Primary IDE Channel
03F8- 03FF 8 Comport 1
0400- 041F 32 SMBus Controller
0480- 04BF 64 Motherboard resources
04D0- 04D1 2 Motherboard resources
0800- 087F 128 Motherboard resources
0A00- 0A0F 16 Motherboard resources
0A10- 0A1F 16 Motherboard resources
0A79- 0A79 256 PNP port
B000- BFFF 4K PCI Express Root Port
B800- B8FF 256 RTL8111b PCI-E Gigabit Ethernet NIC
C000- CFFF 4K PCI Express Root Port
C800- C8FF 256 RTL8111b PCI-E Gigabit Ethernet NIC
D400- D41F 32 Intel ICH8 Family USB Host Controller
D480- D49F 32 Intel ICH8 Family USB Host Controller
D800- D81F 32 Intel ICH8 Family USB Host Controller
D880- D89F 32 Intel ICH8 Family USB Host Controller
DC00- DC1F 32 Intel ICH8 Family USB Host Controller
E000- E00F 16 Intel ICH8 Family Serial ATA Storage Controller
E080- E08F 16 Intel ICH8 Family Serial ATA Storage Controller
E400- E403 4 Intel ICH8 Family Serial ATA Storage Controller
E480- E487 8 Intel ICH8 Family Serial ATA Storage Controller
E800- E803 8 Intel ICH8 Family Serial ATA Storage Controller
E880- E887 8 Intel ICH8 Family Serial ATA Storage Controller
EC00- EC07 8 965 VGA Controller
FF90- FF9F 16 Intel ICH8 Family Serial ATA Storage Controller
FFA0- FFAF 16 Intel ICH8 Family Serial ATA Storage Controller
Notes: This is the IO map after a standard Windows XP SP2 installation
