KT965 Family
KTD-00699-S Public User Manual Date: 2010-04-15 Page 58 of 90
6.2 PCI devices
Bus
#
Device
#
Function
#
Vendor
ID
Device
ID
IDSEL Chip Device Function
0 0 0 8086h 2990h 965 Host bridge
0 2 0 8086h 2992h 965
VGA controller
0 26 0 8086h 2834h ICH8 USB
0 26 1 8086h 2835h ICH8 USB
0 26 7 8086h 283Ah ICH8 USB
0 27 0 8086h 284Bh ICH8 HD-Audio
0 28 0 8086h 283Fh ICH8 PCI 2 PCI Bridge
0 28 4 8086h 2847h ICH8 PCI 2 PCI Bridge
0 28 5 8086h 2849h ICH8 PCI 2 PCI Bridge
0 29 0 8086h 2830h ICH8 USB
0 29 1 8086h 2831h ICH8 USB
0 29 2 8086h 2832h ICH8 USB
0 29 7 8086h 2836h ICH8 USB
0 30 0 8086h 244Eh ICH8 PCI 2 PCI Bridge
0 31 0 8086h 2814h ICH8 ISA Bridge
0 31 2 8086h 2820h ICH8 IDE Controller
0 31 3 8086h 283Eh ICH8 SMBUS Controller
0 31 5 8086h 2825h ICH8 IDE Controller
2 0 0 10ECh 8168h RTL8111b Ethernet
3 0 0 10ECh 8168h RTL8111b Ethernet
4 0 0 - - AD16 -
PCI slot #1
4 1 0 - - AD17 -
PCI slot #2
* - - - - - -
PCI-E slot
* - - - - - -
Mini PCI-E slot #1
When a PCI-E or Mini PCI-E card is used it could change the BUS number on other PCI-E and PCI devices
like RTL8111b.
Note: All PCI slots for the KT965 boards supports PCI BUS Mastering.
