Kontron KT965/Flex - TPM Connector (Unsupported); SPI Connector (Unsupported)

KT965 Family
KTD-00699-S Public User Manual Date: 2010-04-15 Page 49 of 90
4.14 TPM connector (unsupported).
Note
Pull
U/D Ioh/Iol Type Signal
PIN
Signal Type Ioh/Iol
Pull
U/D Note
- - PWR LPC CLK 1 2 GND
- - PWR LPC FRAME# 3 KEY
LPC RST# 5 6 +5V
LPC AD3 7 8 LPC AD2
+3V3 9 10 LPC AD1
LPC AD0 11 12 GND
SMB_CLK 13 14 SMB_DATA
SB3V3 15 16 LPC SERIRQ
GND 17 18 CLKRUN#
SUS_STAT# 19 20 LPC IRQ#
4.15 SPI connector (unsupported).
Note
Pull
U/D Ioh/Iol Type Signal
PIN
Signal Type Ioh/Iol
Pull
U/D Note
SPI_CLK 1 2 SB3V3
10K/ NC 3 4 BOOT0
10K/ SPI_CS1# 5 6 BOOT1
10K/ SPI_MOSI 7 8 MFG
10K/ SPI_MISO 9 10 GND
