Kontron KT965/Flex - AUDIO Header (AUDIO_HEAD)

KT965 Family
KTD-00699-S Public User Manual Date: 2010-04-15 Page 46 of 90
4.11.3 AUDIO Header (AUDIO_HEAD)
Note
Pull
U/D
Ioh/
Iol
Type Signal PIN Signal Type
Ioh/
Iol
Pull
U/D
Note
LFE-OUT 1 2 CEN-OUT
AAGND 3 4 AAGND
FRONT-OUT-L 5 6 FRONT-OUT-R
AAGND 7 8 AAGND
REAR-OUT-L 9 10 REAR-OUT-R
SIDE-OUT-L 11 12 SIDE-OUT-R
AAGND 13 14 AAGND
MIC1-L 15 16 MIC1-R
AAGND 17 18 AAGND
LINE1-IN-L 19 20 LINE1-IN-R
NC 21 22 AAGND
- - PWR GND 23 24 SPDIF-IN
SPDIF-OUT 25 26 GND PWR - -
Signal Description Note
FRONT-OUT-L Front Speakers (Speaker Out Left).
FRONT-OUT-R Front Speakers (Speaker Out Right).
REAR-OUT-L Rear Speakers (Surround Out Left).
REAR-OUT-R Rear Speakers (Surround Out Right).
SIDE-OUT-L Side speakers (Surround Out Left)
SIDE-OUT-R Side speakers (Surround Out Right)
CEN-OUT Center Speaker (Center Out channel).
LFE-OUT Subwoofer Speaker (Low Freq. Effect Out).
NC No connection
MIC1 MIC Input 1
LINE1-IN Line in 1 signals
F-SPDIF-IN S/PDIF Input
F-SPDIF-OUT S/PDIF Output
AAGND Audio Analogue ground
