KT965 Family
KTD-00699-S Public User Manual Date: 2010-04-15 Page 73 of 90
8.3.8 Advanced settings – APM Configuration
BIOS SETUP UTILITY
Advanced
APM Configuration
Power Management/APM [Enabled]
Advanced Resume Event Controls
Resume On Ring [Disabled]
Resume On PME# [Disabled]
Resume On RTC Alarm [Disabled]
Enable or disable APM.
<- Select Screen
|| Select Item
+- change option
F1 General Help
F10 Save and Exit
ESC Exit
v02.59+ (C)Copyright 1985-2005, American Megatrends, Inc.
Note on “Resume On PME#” (When using PCI LAN WOL function):
BIOS version must be KT965009 or higher. The LAN card must have a Standby Voltage input to make it
possible to implement WOL. Very often such cards have a 3 pin connector and one of the pins is the
Standby Voltage. This voltage can be taken directly from the ATX power supply or from the Font Panel
connector pin 1 (or pin 2) or from the Feature connector pin 6. The LAN card must be setup in OS to support
wake after Shutdown.
Feature Options Description
Power Management/APM
Enabled
Disabled
Enable APM
Disable APM
Resume On Ring
Disabled
Enabled
Enable RI signal to generate wake event
Resume On PME#
Disabled
Enabled
Disabled/Enable PME to generate a wake
event. See note below.
Resume On RTC Alarm
Disabled
Enabled
Disabled/Enable RTC to generate a wake
event.
RTC Alarm Date (Days)
15
Key In “+” / “-“ to select.
RTC Alarm Time
12:30:30
Use [ENTER], [TAB] or [SHIFT-TAB] to select
a field.
Use [+] or [-] to configure system Time.
