3.2.8. Configuring Switch VLANs
Changes made to VLANs 4093 and 4094 could impede proper system management.
Three VLANs are preconfigured on the switch, i.e. VLANs 1 (default), 4093 (management) and 4094 (TIPC) (see Figure
9 and Figure 10). VLAN 1 cannot be deleted.
Switch Web UI
Switch CLI (serial, SSH, SOL)
Configuration > VLANs
Add or delete a VLAN by modifying the Allowed
Access VLANs
Change the settings of the ports membership by
modifying the parameters of the Port VLAN
Configuration for Switch 1 or 2
Click on Save
To create a VLAN:
# configure terminal
(config)# vlan <vlan list>
(config-vlan)# ?
A list of possible configuration commands
appears
Proceed with configuration
To include ports in a VLAN and change the ports
membership settings:
# configure terminal
(config)# interface <*|Ethernet> <switch
No.|switch group/port No.|port group>
(config-if)# switchport ?
A list of possible configuration commands
appears
Proceed with configuration
Notes
These configurations must be done for all the
switches in the stack.
VLAN configuration will be propagated to all
the
parameter in the interface command.
