MSH8900
www.symkloud.com // 47
Column Priority lets you set priority levels for
switches. Priority levels are from 1 to 4. The switch
with a priority level of 1 will be the one elected
master upon system power up or when you use the
Start Master Election option.
3.2.13. Configuring Static Routing
To configure routing between VLANs within a stack:
Switch CLI (serial, SSH, SOL)
Configuration > System > IP
Click on Add Route
Proceed with configuration
Click on Save
# configure terminal
(config)# ip route <network address>
<network mask> <gateway>
Perform this configuration on the stack master
switch.
3.3. Accessing a Component via an IPMI Address
From the ipmitool interface, you can access the MS2900 or MS1300 components using their IPMI addresses.
Table 19: IPMI mapping
To direct an ipmitool> CLI command to a component in the platform in which you are logged in:
