KoolMore HZB-160F - Specifications; Dimensions and Connections; Unit Rating

5
SPECIFICATIONS
1) DIMENSIONS/CONNECTIONS
2) Rating
POWER SUPPLY VOLTAGE
1Phase, 110-120/60Hz
MODEL
HZB-160F
CLIMATE CLASS
10-40℃
ELECTRICAL PROTECTION CLASS
I
ICE MAKING RATING (Amps)
8.8Amp
ICE MAKING CAPACITY (KG/24H)
160kg/24Hour
*
REFRIGERANT CHARGE
R290 3.7Oz / 105g
NET WEIGHT(KG)
ICE MAKER
82 lbs
ICE BIN
62 lbs
VESICANT
C
5
H
10
UNIT DIMENSIONS(W X D X H) (mm)
668x 580 x 1610
CONNECTION
POWER CORD----16AWG
WATER SUPPLY----9.52mm diamete
DRAIN----Φ16 SYLPHON BELLOWSS(REAR)
WATER CONSUMPTION(L/24H)
150L
MAX ICE STORAGE CAPACITY(KG)
90Kg
ACCESSORIES
SHOVEL, INSTALLATION KITS, Adjustable feet
RUNNING CONDITIONS
ROOM TEMP 50-110 Fahrenheit
WATER SUPPLY TEMP 41-95 Fahrenheit
WATER SUPPLY PRESSURE 0.04-0.6 MPa
NOTE *: TESTED AT 70 Fahrenheit ROOM TEMPERATURE AND 50 Fahrenheit WATER TEMPERATURE.
951
1610
508
640
668
561
40
486
565
Water Drainage
Port
Water Inlet
Port
448
580
