Korg EK-50L User Manual

Part Names
4
Part Names
Front panel
Rear panel
1.
Cable hook
....................................................................................... page 7
2.
DC 12V jack
( )
..................................................................... page 7
3.
USB TO DEVICE port, USB TO HOST port
( )
........................................................................................................ page 24, 27
4.
FOOT CONTROLLER jack
.............................................. page 8, 29
5.
OUTPUT L/MONO and R jacks
........................................ page 26
6.
AUDIO IN jack
........................................................................... page 26
7.
Headphones jack
( )
................................................................... page 8
8.
Baery compartment
................................................................. page 7
Built-in speakers
(page 8)
Built-in speakers
(page 8)
KeyboardJoystick (page 13)
Display (page 6) Sheet music stand insertion holes (page 8)
1234567
8

Korg EK-50L Specifications

General

Brand	Korg
Model	EK-50L
Category	Electronic Keyboard
Language	English
