Korg EK-50L - Control Panel Layout; Control Panel Overview

Part Names
5
Control panel
1.
MODE section
................................................................................ page 9
STYLE/[MUSIC STYLE] buon
..................................... page 10, 16
SONG/[DEMO SONG] buon
............................................. page 18
2.
KEYBOARD SET/[STS] buon
..................................... page 10, 15
3.
GRAND PIANO buon
.......................................................... page 10
4.
SPEAKER EQ/[SPEAKER OFF] buon
..................... page 13, 26
5.
SETTING/[EFFECT] buon
............................................ page 13, 21
6.
MEDIA buon
............................................................................. page 24
7.
[SHIFT] buon
When seing a function enclosed in white lines for a buon,
hold the [SHIFT] buon down and press that buon.
You may sometimes need to hold down the
[SHIFT] buon and then press another
buon or turn the dial.
This icon is used in these cases.
8.
Dial
..................................................................................................... page 9
9.
CATEGORY buon
t
,
u
......................................................... page 9
10.
Numerical buons, + buon, – buon
............................. page 9
11.
ENSEMBLE buon
.................................................................... page 13
12.
SPLIT buon
................................................................................ page 11
13.
TAP TEMPO/[TEMPO LOCK] buon
.................... page 11, 12
14.
METRONOME/[BEAT SELECT] buon
........................ page 11
15.
TRANSPOSE
♭
,
♯
/[OCTAVE –, +] buon
.......................... page 12
16.
SET LIST section
.................................................................. page 10, 17
• BANK/WRITE buon
• Buons 1–4
17.
STYLE/SONG section
STYLE section
............................................................................ page 15
• VARIATION 1/2, 3/4 buons
• FILL buon
• COUNT IN/BREAK buon
• INTRO/ENDING buon
• Start/stop buon
( )
• SYNCHRO START/STOP buon
• Record buon
( )
SONG section
............................................................................ page 18
• LOOP buon
• A
1
B buon
(A
1
B)
• Rewind buon
( )
• Fast‑forward buon
( )
• Pause buon
( )
• Start/stop buon
( )
• ERASE buon
• Record buon
( )
18.
PART MUTE/[SOUND SELECT] section
................ page 12, 16
Keyboard part
............................................................................ page 10
• LOWER buon
• UPPER 1 buon
• UPPER 2 buon
• UPPER 3 buon
Accompaniment part
............................................................... page 14
• DRUM buon
• PERCUSSION buon
• BASS buon
• OTHER PARTS buon
15
2 3 4
5
6 7
8
9
10
11
12
13
14
16
17
18
1
Style list
Song list Keyboard list
Power buon (
)
(page 7)
VOLUME knob (page 8)
