Part Names
6
Display
Displays the name of the chord played
within the chord recognition range.
USB icon
Displays when a USB ash drive is
plugged into the USB TO DEVICE
port.
: Displays when the style or
song have stopped.
The octave and transpose state are
displayed to the right.
Octave Transpose
: Displays when a style or
song is being played back.
The current measure position or
remaining number of measures are
displayed to the right.
: Displays the tempo
of the style or song.
: Lights up to display the beat
of the style or song.
Tempo lock icon (page 12)
Displays when the tempo is
locked.
Split point (page 11)
Baery indicator
Displays the remaining amount of
baery power when running on
baeries.
Bank
Displays the bank of the currently
selected set list.
Keyboard display
Displays the keys currently played
on the keyboard, and the split point.
These show the current mode and function. When the display is blinking, the
blinking items indicate what operations are in eect.
: Displays when using style mode. The style name and number appear
below on the display.
: Displays when using song mode. The song name and number appear
below on the display.
: Displays when a music style is selected. The music style name and
number appear below on the display.
: Displays when style mode or song mode are in use. The keyboard
set name and number used by the style or song appear below on the display.
: Displays when the sound for each part used in the keyboard set is
selected. The sound name and number appear below on the display.
: Displays when accessing the SETTING functions. The parameter
name, number, value and so on that are being set appear in the display.
