4
Overview
(Quarter Tone version only)
Front Panel
Quarter Tone
The Quarter Tone / Sub Scale section is only available in the Pa600
Quarter Tone version.
QUARTER TONE / SUB SCALE
Use the mini-keyboard to modify the Quarter Tone Scale, and
the four SC Preset buttons to select one of the preset scales. Keep
one of the buttons pressed to memorize the current scale into the
corresponding SC Preset.
Joystick lever
The joystick is on the left side of the
front panel.
JOYSTICK
This joystick triggers different func-
tions, depending on the direction it is
moved towards.
X (+/–) Move the joystick
towards the left (–) to lower the pitch, or towards
the right (+) to raise it. This effect is called the
Pitch Bend.
Y+ Move the joystick forward to trigger Modulation
Y– Move the joystick backward, to trigger the func-
tion assigned in Sound mode.
Overview.fm Page 4 Wednesday, July 4, 2012 11:59 AM
