Effect
173
Pitch/phase modulation effects
16: St.Chorus
(Stereo Chorus)
This effect adds thickness and warmth to the sound by modu-
lating the delay time of the input signal. You can add spread
to the sound by offsetting the phase of the left and right LFOs
from each other.
e: L Dly, e: R Dly
Setting the left and right delay time individually allows you to
control the stereo image.
17: St.HarmnicCho
(Stereo Harmonic Chorus)
This effect applies chorus only to higher frequencies. This can
be used to apply a chorus effect to a bass sound without mak-
ing the sound thinner. You can also use this chorus block with
feedback as a flanger.
e: Hi/Lo Split
This parameter sets the frequency that splits the high and low
range. Only the high range will be sent to the chorus block.
Pitch/Phase Mod.
a
LFO Wave (LFO Waveform)
Selects LFO Waveform
Tr iangle, Sine
b
LFO Phase –180...+180deg
Sets the LFO phase difference between the left and right ☞ Fx:10
c
Freq (LFO Frequency) 0.02...20.00Hz
Sets the LFO speed ☞ Fx:09,
(Source)
Selects the modulation source of LFO speed
Off...Tempo
(Amount) –20.00...+20.00Hz
Sets the modulation amount of LFO speed
d
BPM/MIDI Sync Off, On
Switches between using the frequency of the LFO speed and using
the tempo and notes
☞ Fx:09,
BPM
Selects MIDI Clock and assigns tempo
MIDI, 40...240
☞ Fx:09
Base (Base Note)
Selects the type of notes that specify the LFO speed ☞ Fx:09
Times 1...16
Sets the number of notes that specify the LFO speed ☞ Fx:09
e
L Dly (L Pre Delay)
Sets the delay time for the left channel
0.0...50.0ms
☞
R Dly (R Pre Delay)
Sets the delay time for the right channel
0.0...50.0ms
☞
f
Depth
Sets the depth of LFO modulation
0...100
(Source) Off...Tempo
Selects the modulation source of the LFO modulation depth
(Amount) –100...+100
Sets the modulation amount of the LFO modulation depth
g
Pre EQ Trim
Sets the EQ input level
0...100
h
LoEQ (Pre Low EQ Gain)
Sets the gain of Low EQ
–15.0...+15.0dB
HiEQ (Pre High EQ Gain)
Sets the gain of High EQ
–15.0...+15.0dB
i
W/D (Wet/Dly) –Wet...–1:99, Dry, 1:99...Wet
Sets the balance between the effect and dry sounds
☞ Fx:10,
(Source) Off...Tempo
Selects the modulation source of the effect balance
(Amount)
Sets the modulation amount of the effect balance
–100...+100
Chorus
Chorus
Left
Right
LFO Phase
Wet / Dry
Wet / Dry
Stereo In - Stereo Out
EQ Trim
EQ Trim
LEQ
HEQ
LEQ
HEQ
LFO: Tri / Sine
a
LFO Wave (LFO Waveform)
Selects LFO Waveform
Tr iangle, Sine
b
LFO Phase –180...+180deg
Sets the LFO phase difference between the left and right ☞ Fx:10
c
Freq (LFO Frequency) 0.02...20.00Hz
Sets the LFO speed ☞ Fx:09,
(Source)
Selects the modulation source of LFO speed
Off...Tempo
(Amount) –20.00...+20.00Hz
Sets the modulation amount of LFO speed
d
BPM/MIDI Sync Off, On
Switches between using the frequency of the LFO speed and using
the tempo and notes
☞ Fx:09,
BPM
Selects MIDI Clock and assigns tempo
MIDI, 40...240
☞ Fx:09
Base (Base Note)
Selects the type of notes that specify the LFO speed ☞ Fx:09
Times 1...16
Sets the number of notes that specify the LFO speed ☞ Fx:09
e
Dly (Delay Time)
Sets the delay time from the original sound
0.0...50.0ms
Hi/Lo Split (High/Low Split Point) 1...100
Sets the frequency split point between the high and low range ☞
f
Depth
Sets the depth of LFO modulation
0...100
(Source) Off...Tempo
Selects the modulation source of the LFO modulation depth
(Amount) –100...+100
Sets the modulation amount of the LFO modulation depth
g
Feedback
Sets the feed back amount of the chorus block
–100...+100
☞
HiDamp (High Damp) 0...100%
Sets the high range damping amount of the chorus block
h
Lo Level (Low Level)
Sets the low range output level
0...100
Hi Level (High Level)
Sets the high range (chorus) output level
0...100
i
W/D (Wet/Dly) Dry, 1:99...99:1, Wet
Sets the balance between the effect and dry sounds
(Source) Off...Tempo
Selects the modulation source of the effect balance
(Amount)
Sets the modulation amount of the effect balance
–100...+100
Left
Right
Feedback
LFO Phase
LFO: Tri / Sine
Wet / Dry
Wet / Dry
High Damp
Stereo In - Stereo Out
Low Level
Low Level
High Level
High Level
High/Low Split Point
High Damp
Chorus/Flanger
Chorus/Flanger
