Kossel Linear Plus - Page 6

Shenzhen Anycubic Technology Co., Ltd.
Parts List
No.
Items/Quantity
No.
Items/Quantity
A01
Top triangle × 3
B01
XYZ Motor × 3 (with wire)
A02
Bottom triangle × 3
B02
Print head set × 1
A03
Effector × 1
B03
4010 fan × 1 (with wire & end)
A04
Horseshoe fixture × 1
B04
4010 air blower × 1 (with wire & end)
A05
Radiator cover × 1
B05
Limit switch × 3
A06
Air nozzle × 1
B06
Wire for limit switch× 3 pairs
A07
Belt tensioner × 3
B07
Wire terminal for limit switch × 3
A08
Stop blocks × 6 (Pulley× 3)
B08
Extrusion motor × 1
A09
Carriage × 3 (Pulley only)
B09
ANYCUBIC mainboard × 1
A10
Extrusion bearing holder × 1
B10
Al-fin × 5
A11
Extrusion fixture × 1
B11
A4988 driver × 5
A12
Extruder rack × 1
B12
LCD 2004 × 1 (with pin board & wire)
A13
Shaft sheath × 1
B13
USB wire × 1
A14
Mainboard holder × 1
B14
Power adaptor × 1
A15
LCD cover × 1
B15
SD card × 1
A16
Limit blocks for print platform × 6
C01
M5*25 screw × 9 (Pulley only)
D01
240mm Al-extrusion × 9 (300mm for
Linear Plus)
C02
M3*20 screw × 9
D02
680mm Al-extrusion × 3
C03
M3*16 screw × 17
D03
Idler wheel × 3
C04
M3*12 screw × 1 (Pulley × 14)
D04
Synchronizing wheel × 3
C05
M3*10 screw × 8
D05
Carbon fiber tube set × 6
C06
M3*8 screw × 50 (Pulley × 20)
D06
450mm Linear rail × 3 (Linear only)
C07
M2.5*12 screw × 11
D07
Pulley wheel (Bearing) × 9 (Pulley only)
C08
M2*5 screw × 8
D08
4.5m Synchronous belt × 1
C09
Ø4-7-0.5 washer × 2
D09
Belt tension spring × 3
C10
M3 flange nut × 18 (Linear only)
D10
Extrusion wheel × 1
C11
M4 square nut × 67 (Pulley × 64)
D11
Extrusion bearing × 1
C12
M5 hex nut × 9 (Pulley only)
D12
Extrusion spring × 1
C13
M4 hex nut × 3
D13
M6 Quick connector × 1
C14
M3 hex nut × 16 (Pulley × 19)
D14
0.6m PTFE feeding pipe × 1
C15
M4*8 screw × 6
D15
0.8m Strap × 1
C16
M4*10 screw × 59 (Pulley × 56)
D16
PTFE washer × 4
C17
M4*12 screw × 1
D17
Ø200mm Glass plate × 1 (Ø240mm for
Linear Plus)
C18
M4*25 screw × 3
Other
Hex key set (1.5/2/2.5/4mm) × 1
Rubber glove × 1 pair
Test filament × 1
