DSP-62-AEC, DSP-62-UC – Mounting the Device
SETUP DIP-switches are FOR FACTORY USE ONLY.
To operate and control DSP-62-AEC, DSP-62-UC via the web pages (see Using the
Embedded Webpages on page 14), connect the device via Ethernet (see Connecting through
Ethernet on page 11).
Connecting through Ethernet
To connect the device via Ethernet, use either of these methods:
• Directly to the PC using a crossover cable (see Connecting Ethernet Port Directly to a
PC on page 11).
• Via a network hub, switch, or router, using a straight-through cable (see Connecting
Ethernet Port via a Network Hub on page 13).
If you want to connect via a router and your IT system is based on IPv6, ask your IT
department for specific installation instructions.
Connecting Ethernet Port Directly to a PC
You can connect the Ethernet port of your device directly to the Ethernet port on your PC
using a crossover cable with RJ-45 connectors.
This type of connection is recommended for identifying the device
with the factory configured default IP address.
After connecting the device to the Ethernet port, configure your PC as follows:
1. Click Start > Control Panel > Network and Sharing Center.
2. Click Change Adapter Settings.
3. Highlight the network adapter you want to use to connect to the device > click Change
settings of this connection.
The Local Area Connection Properties window for the selected network adapter opens
as shown in Figure 9.
