DSP-62-AEC, DSP-62-UC – Technical Specifications
53
DSP-62-UC Technical Specifications
Inputs
2 HDMI
On female HDMI connectors
1 Unbalanced Stereo Audio
On a 3.5mm mini jack
4 Balanced Mono Audio
On 3-pin terminal block connector
Outputs
1 Balanced Stereo Audio
On a 5-pin terminal block connector
1 HDBaseT
On a RJ-45 connector
Ports
1 USB Audio
On a female mini USB-B connector
1 RS-232
On a 3-pin terminal block
1 Ethernet
On an RJ-45 female connector
Line/Mic Level
Input
Impedance Unbalanced
Impedance Balanced
Impedance Microphone
7.6KΩ
3.8KΩ
3.8KΩ
Nominal level Unbalanced
Nominal level Balanced
0dBV (0.77Vrms)
6.8dBu (1.54Vrms)
Maximum level (Balanced)
+8dBu (2Vrms)
Sensitivity Unbalanced
Sensitivity Balanced
Full power @ 0dBV (0.77Vrms)
Full power @ +6dBu (1.54Vrms)
Phantom Power
48 VDC on/off per input
Line/Mic Level
Output
Impedance Unbalanced /
Balanced
500Ω
Frequency Response
20Hz — 20kHz @ +/–1dB
S/N Ratio
>85dB, 20Hz — 20kHz, at unity gain
(unweighted)
Audio THD + Noise
<0.01%, 20 Hz — 20kHz, at unity gain
Crosstalk
<–85dB, 20Hz to 20kHz
Video
Max Bandwidth
10.2Gbps (3.4Gbps per graphic channel)
Max Resolution
4K@60Hz (4:2:0) DSP-62-UC
Compliance
HDMI and HDCP 2.2, and HDBT 2.0
User Interface
Indicators
Power and audio port status LEDs
Controls
Input selection buttons
Control RS-232
Baud Rate
115200
Supported
Web Browsers
Windows
Chrome
Power
Consumption
950mA
Source
PoE or 48V DC 1.36A adapter
Environmental
Conditions
Operating Temperature
0° to +40°C (32° to 104°F)
Storage Temperature
-40° to +70°C (-40° to 158°F)
Humidity
10% to 90%, RHL non-condensing
Regulatory
Compliance
Safety
CE, FCC
Environmental
RoHs, WEEE
Enclosure
Size
MegaTOOLS®
Type
Aluminum
Cooling
Convection Ventilation
General
Net Dimensions (W, D, H)
18.75cm x 14.5cm x 2.54cm (7.38" x 5.7" x 1")
Shipping Dimensions (W, D, H)
35.1cm x 21.2cm x 7.2cm (13.81" x 8.34" x 2.83")
Net Weight
0.7kg (1.54lbs)
Shipping Weight
1.29kg (2.84lbs) approx.
Accessories
Included
Power adapter cord
