To enable security settings:
• Click the security disabled icon ( ).
Viewing the Matrix Area
The matrix area in the DSP page shows the inputs that are currently routed to the outputs.
Figure 18: DSP Page – Matrix Settings
Clicking an IN or OUT button or a signal processing module (for example, Exp), highlights the
routing path.
Figure 19: Matrix Area – Routing Path
When opening the processing view, the sliders of the Inputs routed to the Outputs appear.
Figure 20: Processing View – Inputs Routed to Outputs
