Linking Analog Pairs
To link analog input or output pairs, see Linking Analog Inputs and Outputs on page 18.
Mixing Audio Signals
Mix the audio signals and store/recall mixing snapshots via the Mixer page.
DSP-62 enables performing the following tasks:
• Defining Input and Output Parameters on page 36.
• Defining Snapshots on page 37.
Defining Input and Output Parameters
Set audio parameters for each input and output.
To set input/output parameters:
1. In the Navigation pane, click Mixer. The Mixer page appears.
Figure 42: Mixer Page
An input/output frame with a white rim indicates that this input/output is currently connected to
an output/input, respectively.
2. Use the slider or enter the desired value and press Enter (on your PC) to set the
volume.
View the current gain and the input/output name (see Input / Output Channels Operation
on page 19).
