Kramer DSP-62-UC User Manual

Kramer Electronics Ltd.
DSP-62-AEC, DSP-62-UC – Audio and Video Settings
39
Audio and Video Settings
Audio and video settings enable performing the following settings:
• Defining Audio Settings on page 39.
• Defining Video Settings on page 40.
Defining Audio Settings
Set the DSP-62 analog audio I/O configuration, system presets and amplifier settings using
the A/V Settings page.
Amplifier settings are only relevant to DSP-62.
To define audio settings:
1. In the Navigation pane, click A/V Settings. The A/V Settings page appears.
Figure 48: A/V Settings Page
2. In the System Preset drop-down box, select a preset (default or System 2 to System
10) and click LOAD, SAVE AS or SAVE.
The current preset is loaded or saved.
System Presets contain all the system configuration including Snapshot
configuration and excluding IP settings.
Audio settings are defined.
