3. Click the Off button . The High Pass Filter module turns on .
Figure 29: Processing View – HPF Module
4. Set the cut-off frequency.
HPF is adjusted.
Using Compression Module
Use the Compressor module to reduce the signal dynamic range which is the difference
between the loudest and quieter sounds (for example, the difference between a scream and a
whisper), making the sound seem more natural.
To adjust the compressor settings:
1. In the Navigation pane, click DSP. The DSP (Main) page appears.
2. Click Comp. The button turns blue and the Compressor module pane appears.
3. Click the Off button . The Comp module turns on .
Figure 30: Processing View – Compressor Module
