KDS-7-MNGR – Operating KDS-7-MNGR
11
4. Input username and password (default username/password: admin/admin) and click
Sign In to enter the main page of web UI.
See Defining User Management on page 57 for defining new users.
Connecting Ethernet Port Directly to a PC
You can connect the Ethernet port of KDS-7-MNGR directly to the Ethernet port on your PC
using a crossover cable with RJ-45 connectors.
This type of connection is recommended for identifying KDS-7-MNGR
with the factory configured default IP address.
After connecting KDS-7-MNGR to the Ethernet port, configure your PC as follows:
1. Click Start > Control Panel > Network and Sharing Center.
2. Click Change Adapter Settings.
3. Highlight the network adapter you want to use to connect to the device and click Change
settings of this connection.
The Local Area Connection Properties window for the selected network adapter appears
as shown in Figure 4.
Figure 4: Local Area Connection Properties Window
4. Highlight either Internet Protocol Version 6 (TCP/IPv6) or Internet Protocol Version 4
(TCP/IPv4) depending on the requirements of your IT system.
5. Click Properties.
The Internet Protocol Properties window relevant to your IT system appears as shown in
Figure 5 or Figure 6.
