Kramer VM-214DT User Manual

Kramer Electronics Ltd.
VM-214DT – Operating the VM-214DT Remotely Using the Web Pages
23
#
Item
Description
11
Load Configuration
Button
Click to load a previously saved configuration.
12
Factory Reset
Button
Click to reset the device to factory default parameters. After the success
message is displayed, power cycle the device.
13
Set Name Button
Click to save changes to the device name.
14
Set UDP Port
Number Button
Click to save changes to the UDP port number.
Changing the DHCP mode or the static IP address of the device will result in the warning
shown in Figure 23.
The changes will not take effect until after you reset the device.
Communication with the device will be lost and you will be required to enter the new address
in your browser.
Figure 23: The IP Address Changes Popup Warning

Kramer VM-214DT Specifications

General

Brand	Kramer
Model	VM-214DT
Category	Switch
Language	English
