Kramer VS-66H

Your VS-66H 6x6 HDMI Matrix Switcher
KRAMER: SIMPLE CREATIVE TECHNOLOGY
8
4.1 Using the IR Transmitter
You can use the RC-IR3 IR transmitter to control the machine via the
built-in IR receiver on the front panel or, instead, via an optional external IR
receiver
1
. The external IR receiver can be located up to 15 meters away
from the machine. This distance can be extended to up to 60 meters when
used with three extension cables
2
Before using the external IR receiver, be sure to arrange for your Kramer
dealer to insert the internal IR connection cable
20F
3
with the 3.5mm connector
that fits into the REMOTE IR opening on the rear panel. Connect the
external IR receiver to the REMOTE IR 3.5mm connector.
1 Model: C-A35M/IRR-50
2 Model: C-A35M/A35F-50
3 P/N: 505-70434010-S
