Kramer VS-66H

Connecting a VS-66H 6x6 HDMI Matrix Switcher
KRAMER: SIMPLE CREATIVE TECHNOLOGY
10
6 Connecting a VS-66H 6x6 HDMI Matrix Switcher
To connect the VS-66H 6x6 HDMI Matrix Switcher, as illustrated in the
example in
Figure 2, do the following
1
1. Connect
:
2
2. Connect
up to six HDMI sources (for example, DVD players) to the six
INPUT HDMI connectors.
3
3. If required, connect a PC and/or controller to the RS-232 port (see section
the six OUTPUT HDMI connectors to up to six HDMI acceptors
(for example, LCD displays with built-in speakers).
7.4) and/or the ETHERNET port (see section 7.5).
4. Connect the power connector to the mains electricity (not shown in
Figure
2).
5. If required, acquire the EDID (see section
7.1)
Press the SELECT IN and OUT buttons to choose which HDMI input to
route to a selected output.
1 Switch OFF the power on each device before connecting it to your VS-66H. After connecting your VS-66H, switch on its
power and then switch on the power on each device
2 You do not have to connect all the HDMI sources
3 You do not have to connect all the outputs
