3 Overview
The VS-66H is a high quality 6x6 matrix switcher for HDMI signals.
In particular, the VS-66H features:
• Support for up to 1.65Gbps bandwidth per graphic channel
1
• HDCP support (High Definition Digital Content Protection)
• I-EDIDPro™ Kramer Intelligent EDID Processing™, an intelligent
EDID handling and processing algorithm that ensures Plug and Play
operation for HDMI systems
• An OFF button to disconnect an output
• A PANEL LOCK button to prevent unwanted tampering with the
buttons on the front panel
• 12 preset memory locations for quick access to common configurations
• Installation into one vertical space of a standard 19” professional rack
enclosure
Control the VS-66H using the front panel buttons, or remotely via:
• RS-232 serial commands transmitted by a touch screen system, PC, or
other serial controller
• The Kramer Infrared remote control transmitter
• The ETHERNET
• An external remote IR receiver (optional), see section
4.1
3.1 Defining EDID
The Extended Display Identification Data (EDID
2
7.1
) is a data-structure,
provided by a display, to describe its capabilities to an HDMI source. The
EDID enables the VS-66H to “know” what kind of monitor is connected to
the output. The EDID includes the manufacturer’s name, the product type,
the timing data supported by the display, the display size, luminance data
and (for digital displays only) the pixel mapping data. See section for
details of how to acquire the EDID.
1 Suitable for resolutions up to UXGA at 60Hz, and for all HD resolutions
2 Defined by a standard published by the Video Electronics Standards Association (VESA)
