Always switch off the power to each device before connecting it to your
VS-88H. After connecting your VS-88H, connect its power and then
switch on the power to each device.
To connect the VS-88H as illustrated in the example in Figure 3:
1. Connect up to eight DVI sources (for example, DVD players) to the IN DVI
connectors.
2. Connect the OUT DVI connectors to up to eight DVI acceptors (for example,
DVI displays).
3. If required, connect a PC and/or controller to the RS-232 port (see
Section5.1) and/or the Ethernet port (see Section 5.2).
4. If required, acquire the EDID (see Section 6.4).
