5.2 Using the Ethernet Connection
You can connect to the VS-88H via Ethernet using either of the following methods:
 Direct connection to the PC using a crossover cable (see Section 5.2.1)
 Connection via a network hub, switch, or router, using a straight-through cable
(see Section 5.2.2)
5.2.1 Connecting the Ethernet Port Directly to a PC (Crossover Cable)
You can connect the Ethernet port of the VS-88H to the Ethernet port on your PC,
via a crossover cable with RJ-45 connectors.
This type of connection is recommended for identifying the
VS-88H with the factory configured default IP address.
After connecting the Ethernet port, configure your PC as follows:
1. Right-click the My Network Places icon on your desktop.
2. Select Properties.
3. Right-click Local Area Connection Properties.
4. Select Properties.
The Local Area Connection Properties window appears.
5. Select the Internet Protocol (TCP/IP) and click the Properties Button (see
Figure 4).
