KRAUSE ProTec - Page 71

71
Prod. No. 910165 910172 910189 910196 910202
Modul No. 2206 2207 2208 2209 2210
Working height 8.30 m 9.30 m 10.30 m 11.30 m 12.30 m
Scaffold height 7.30 m 8.30 m 9.30 m 10.30 m 11.30 m
Standing height 6.30 m 7.30 m 8.30 m 9.30 m 10.30 m
Prod.
No.
Description Quantity Quantity Quantity Quantity Quantity
Weight
in kg
915016 Vertical frame 2 m 6 7 8 9 10 5.3
915023 Vertical frame 1 m 2 2 2 2 2 2.7
911001 Platform 2 2 2 3 3 13.0
912800 Diagonal brace 8 8 10 12 14 1.5
912206 Rail brace 8 8 8 12 12 1.2
912848 Base brace 2 2 2 2 2 5.0
914071 Stabiliser 2 2 2 2 2 6.5
914095 Outrigger 2 4 4 4 4 8.0
913555 Transversal board 2 2 2 2 2 1.1
913517 Longitudinal board 2 2 2 2 2 3.2
914026 Foot plate 4 4 4 4 4 0.6
914309*
Castor 150 mm,
height-adjustable
1 1 1 1 1 14.0
704405 Gravity pin 16 18 20 22 26 0.1
Total weight in kg 151,0 172,0 181,0 207,0 216,0 –
560815 Manual 1 1 1 1 1 –
Packs required for
specied standing
height
0 + 1 + 2 + 6 + * 0 + 1 + 2 + 3 + * 0 + 1 + 2 + 3 + 6 + * 0 + 1 + 2 + 3 + 4 + * 0 + 1 + 2 + 3 + 4 + 6 + *
Parts list for ProTec mobile aluminium scaffold (continued)
