KRAUSE ProTec - 6. Technical data

70
Parts list of ProTec mobile aluminium scaffold, length 2.00 m, width 0.70 m
6. Technical data
Prod. No. 910110 910097 910134 910141 910158
Modul No. 2201 2202 2203 2204 2205
Working height 2.90 m 4.30 m 5.30 m 6.30 m 7.30 m
Scaffold height 2.30 m 3.30 m 4.30 m 5.30 m 6.30 m
Standing height 0.90 m 2.30 m 3.30 m 4.30 m 5.30 m
Prod.
No.
Description Quantity Quantity Quantity Quantity Quantity
Weight
in kg
915016 Vertical frame 2 m 2 2 3 4 5 5.3
915023 Vertical frame 1 m 0 2 2 2 2 2.7
911001 Platform 1 1 1 1 2 13.0
912800 Diagonal brace 1 2 4 6 6 1.5
912206 Rail brace 1 6 4 4 8 1.2
912848 Base brace 0 0 2 2 2 5.0
914071 Stabiliser 0 0 2 2 2 6.5
914095 Outrigger 0 0 0 0 2 8.0
913555 Transversal board 0 2 2 2 2 1.1
913517 Longitudinal board 0 2 2 2 2 3.2
914026 Foot plate 4 4 4 4 4 0.6
914309*
Castor 150 mm,
height-adjustable
1 1 1 1 1 14.0
704405 Gravity pin 0 4 10 12 14 0.1
Total weight in kg 43,0 65,0 95,0 103,0 142,0 –
560815 Manual 1 1 1 1 1 –
Packs required for
specied standing
height
0 + * 0 + * + Teile 0 + 1 + * 0 + 1 + 6 + * 0 + 1 + 2 + *
