10
Operation (continued)
3
Install a Knob on a Door (continued)
f. Position the jig with stops, as shown. Hold the jig rmly against the face of the door and drill
the hole using the Fixed Center Drill Guide (F).
g. Flip the tool on it’s reverse side and repeat the process for the opposite door.
h. Install the knobs and repeat the process for each door.
3f
3f
3g
F
Right-hand door
Left-hand door
To Next Page
