3
Pre-Assembly
Review this section before you begin. Ensure you have all tools/materials on hand and
compare the package with the items listed in the Product Description section. If any
item appears missing or lost, do not use this product. Contact Technical Support or
return product to place of purchase.
Recommended Tools/Materials
Clamp Pencil
Product Description
F
B
A
C
D
E
G
H
Part Description Part Description
A Shelf Pin Jig E** Indexing pin
B Fence F Jig extension
C* Drill bit G Hex wrench
D Stop collar with set screw H 1/4" or 5 mm Shelf pins (4x)
*If replacement or different size drill bits are needed, 1/4" or 5 mm drill bits are available
separately.
**The indexing pin is double ended for both 1/4" and 5 mm shelf pin holes.
