Clamp the Jig
WARNING Follow your clamp
manufacturer’s safety guidelines. Keep
your hands clear when clamping to avoid
pinch points. The clamping limit on this
jig is 300 lbs.
a. Use a clamp in the location shown
below to secure the jig (A) in place.
b. If using two connected jigs, clamp
both.
Tip If your cabinet is already assembled,
remove the fence and place the jig
against the back of the cabinet using the
same reference point as the front and
carefully hold in place while you drill your
rst hole. Then use the jig extender and
index pin to continue.
Frameless Cabinets
1
Attach the Fence to the Jig
a. Insert the fence (B) into the jig (A) base.
b. Slide the fence (B) horizontally to secure it in place.
A
B
B
A
Note To remove the fence (B), slide the fence horizontally and pull away from the
jig(A).
