TECHNICAL DATA 6
49
OPTIMASS 7000
www.krohne.com10/2015 - 4001016303 - MA OPTIMASS 7000 R03 en
Dimension B [inches]
T/S 10 T/S 15 T/S 25 T/S 40 T/S 50
Tri-clover
Tri-cloverTri-clover
Tri-clover
½" 23.5 ±0.08 - - - -
¾" - 25 ±0.08 - - -
1" - 26.2 ±0.08 - - -
1½" - - 33.7 ±0.08 - -
2" - - - 42.4 ±0.08 -
3" - - - - 53.3 ±0.08
Tri-clamp DIN 32676
Tri-clamp DIN 32676Tri-clamp DIN 32676
Tri-clamp DIN 32676
DN10 23.2 ±0.08 - - - -
DN15 - 24.7 ±0.08 - - -
DN25 - - 31 ±0.08 - -
DN40 - - - 40 ±0.08 -
DN50 - - - - 47 ±0.08
Tri-clamp ISO 2852
Tri-clamp ISO 2852Tri-clamp ISO 2852
Tri-clamp ISO 2852
1" - 26.2 ±0.08 - - -
1½" - - 33.7 ±0.08 - -
2" - - - 42.4 ±0.08 -
3" - - - - 53.3 ±0.08
