A - 1
Appendix
A1 Initial hitch up
For transport reasons, the feeder wagon is supplied without the articulated shaft attached and with the covers not
fully assembled. Before commissioning, the feeder wagon must be fully assembled and adapted to suit the type of
tractor used to tow it.
The following parts are supplied loose. These parts must be stowed in the storage compartment of the wagon.
1 Articulated shaft
2 Control
3 Electrical cable for lights
4 Paint spray can
5 Operating instructions
6 Attachment shackle
7 Fittings (in the box)
not in the picture:
Tarpaulin without metal eyelets (x 1)
Tarpaulin with 58 metal eyelets - (x 1)
Metal rods (x 2)
Ropes (x 27)
Tension ropes (x 2)
KDW01052
1
4
5
7
6
32
