3
SEATPOST INSTALLATION
MINIMUM INSERTION DISTANCE
All seat post models must be inserted into the bicycle’s seat tube
to cover the minimum insertion line indicated on the seat post.
Insufficient insertion of the
seat post into the bicycle
frame’s seat tube could
result in damage to the seat
post and/or bicycle and
may result in a loss of control
of the bicycle which may
lead to serious injury or
death.
SEAT COLLAR TORQUE
Tighten your frame’s seat collar to a maximum torque of 7 N-m. Do
not over torque your frame’s seat collar as this may inhibit proper
function of your seat post.
6-7 N-m
Do not over torque your
frame’s seat collar as this
may inhibit proper function
of your seat post.
Seat Collar
To Next Page
