5
SADDLE INSTALLATION
Using a flathead screwdriver, remove the air valve cap from the
top end of the stanchion tube.
At this point, the lower floating clamp cradle and lower clamp
body can rotate freely and be correctly oriented to the front of the
bicycle.
NOTE: The low end of the lower floating clamp cradle and lower
clamp body must point toward the front of the bicycle.
Clamp Body
Clamp Cradle
Air Valve Cap
To Next Page
