1 Supplementary Operating Manual
21 of 48
AmaControl
2301.83/04-EN
Start End Description Data type
8228 8228 Number of hours of the current day (internal time) 0-23h u 16bit
8232 8232 Module condition, motor temperature
High byte: error number
Low byte: module condition, bit-coded
Bit 0 = active
Bit 1 = warning
Bit 2 = fault
Bit 3 = re-start delay
Bit 4 = interlocked
u 16bit
8233 8233 Motor temperature sensor, resistance actual value
1...65,535Ω, 0 = not applicable
u 16bit
8234 8234 Module condition, temperature 1
High byte: error number
Low byte: module condition, bit-coded
Bit 0 = active
Bit 1 = warning
Bit 2 = fault
Bit 3 = re-start delay
Bit 4 = interlocked
u 16bit
8235 8235 Temperature sensor 1, resistance actual value
1...65,535Ω, 0 = not applicable
u 16bit
8236 8236 Module condition, temperature 2
High byte: error number
Low byte: module condition, bit-coded
Bit 0 = active
Bit 1 = warning
Bit 2 = fault
Bit 3 = re-start delay
Bit 4 = interlocked
u 16bit
8237 8237 Temperature sensor 2, resistance actual value 1 - 65,535Ω, 0 = not
applicable
u 16bit
8238 8238 Module condition, leakage 1
High byte: error number
Low byte: module condition, bit-coded
Bit 0 = active
Bit 1 = warning
Bit 2 = fault
Bit 3 = re-start delay
Bit 4 = interlocked
u 16bit
8239 8239 Leakage 1, resistance actual value
1...65,535 Ω, 0 = not applicable
u 16bit
8242 8242 Module condition, analog input
High byte: error number
Low byte: module condition, bit-coded
Bit 0 = active
Bit 1 = warning
Bit 2 = fault
Bit 3 = re-start delay
Bit 4 = interlocked
u 16bit
8243 8243 Analog input actual value
Current = value / 10
0.0...6553.5 mA
u 16bit
8244 8244 Module condition, current sensor 1
High byte: error number
Low byte: module condition, bit-coded
Bit 0 = active
Bit 1 = warning
Bit 2 = fault
Bit 3 = re-start delay
Bit 4 = interlocked
u 16bit
