1 Supplementary Operating Manual
24 of 48
AmaControl
2301.83/04-EN
Start End Description Data type
8295 8295 Temperature sensor 2, actual value
Temperature = (value - 32768) / 100-327.00°C…+327.00°C
65535 = not available
s 16offset
8296 8296 Phase voltage L10...65535V u 16bit
8297 8297 Phase voltage L20...65535V u 16bit
8298 8298 Phase voltage L30...65535V u 16bit
8299 8299 Frequency between L1 and L2
3…65535 motor supply frequency in Hz
0 = not assigned
1 = frequency 0Hz
2 = incorrect phase sequence
u 16bit
8300 8301 Reactive power actual value
0...4.294.967.295 Var
Low word first
u 16bit
8302 8303 Effective power actual value
0...4,294,967,295W
Low word first
u 16bit
8304 8305 Apparent power actual value
0...4.294.967.295VA
Low word first
u 16bit
8306 8307 Active energy meter actual value
Energy = value / 100kWh
0...4,294,967,295
Low word first
u 16bit
8308 8309 Reactive energy meter actual value
Energy = value / 100 kVarh
0...4,294,967,295
Low word first
u 16bit
8354 8355 Event memory: last event, time stamp
0...4,294,967,295seconds elapsed since 01/01/1970 00:00:00,
POSIX format
u 16bit
8356 8356 Event memory: last event, error number u 16bit
8432 8432 Sum over lifetime:
motor temperature, static tripping
Tripping
The following error numbers are counted: {2},{15},{38},{39},{55},{79}
u 16bit
8433 8433 Sum over lifetime:
motor temperature, static tripping
Interlocked tripping
The following error numbers are counted: {2},{15},{38},{39},{55},{79}
u 16bit
8434 8434 Sum over lifetime:
motor sensor, short circuit
Tripping
The following error numbers are counted: {8},{40}
u 16bit
8435 8435 Sum over lifetime:
motor sensor, open circuit
Tripping
The following error numbers are counted: {10},{41}
u 16bit
8436 8436 Sum over lifetime:
temperature sensor 1, temperature exceeded
Tripping
The following event numbers are counted: {56},{57}
u 16bit
8437 8437 Sum over lifetime:
temperature sensor 1, temperature exceeded
Interlocked tripping
The following error numbers are counted: {56},{57}
u 16bit
