1 Supplementary Operating Manual
23 of 48
AmaControl
2301.83/04-EN
Start End Description Data type
8253 8253 Module condition, phase overvoltage
High byte: error number
Low byte: module condition, bit-coded
Bit 0 = active
Bit 1 = warning
Bit 2 = fault
Bit 3 = re-start delay
Bit 4 = interlocked
u 16bit
8254 8254 Module condition, relay monitoring
High byte: error number
Low byte: module condition, bit-coded
Bit 0 = active
Bit 1 = warning
Bit 2 = fault
Bit 3 = re-start delay
Bit 4 = interlocked
u 16bit
8255 8255 Pump runtime while running despite tripping detected
Time = value * 10min
0...655 350minutes
u 16bit
8256 8256 Module condition, frequency of starts monitoring
High byte: error number
Low byte: module condition, bit-coded
Bit 0 = active
Bit 1 = warning
Bit 2 = fault
Bit 3 = re-start delay
Bit 4 = interlocked
u 16bit
8258 8258 Module condition, general monitoring
High byte: error number
Low byte: module condition, bit-coded
Bit 0 = active
Bit 1 = warning
Bit 2 = fault
Bit 3 = re-start delay
Bit 4 = interlocked
u 16bit
8260 8260 Module condition, switching input
High byte: module condition, acc. to error list
Low byte: module condition, bit-coded
Bit 0 = active
Bit 1 = warning
Bit 2 = fault
Bit 3 = re-start delay
Bit 4 = interlocked
u 16bit
8268 8269 Totalled operating time
Operating time = value * 10 minutes
0...4 294 967 296minutes
Low word first
u 32bit
8270 8271 Totalled operating time with active warning
Operating time = value * 10 minutes
0...4 294 967 296minutes
Low word first
u 32bit
8274 8275 Totalled non-operating time
Non-operating time = value * 10 minutes
0...4 294 967 296minutes
Low word first
u 32bit
8292 8292 Motor temperature actual value
Temperature = (value - 32768) / 100-327.00°C…+327.00°C
s 16offset
8294 8294 Temperature sensor 1, actual value
Temperature = (value - 32768) / 100-327.00°C…+327.00°C
65535 = not available
s 16offset
