1 Supplementary Operating Manual
32 of 48
AmaControl
2301.83/04-EN
Start End Data type Description
10912 10912 Event memory: index, current event, position in rolling event memory
0...65,535
u 16bit
10913 10913 Event memory: index, current measured value set Position in rolling
measured value memory 0...65,535
u 16bit
10914 10914 Event memory: last event, time stamp 0...4,294,967,295Seconds elapsed
since 01/01/1970 00:00:00, POSIX format
u 32bit
10916 10916 Event memory: last event, error number u 16bit
10917 10917 Event memory: last event, free value u 16bit
10996 10996 Sum over lifetime:
temperature sensor 1, temperature exceeded
Tripping
The following event numbers are counted: {56},{57}
u 16bit
10997 10997 Sum over lifetime:
temperature sensor 1, temperature exceeded
Interlocked tripping
The following error numbers are counted: {56},{57}
u 16bit
10998 10998 Sum over lifetime:
temperature sensor 1, short circuit
Tripping
The following event numbers are counted: {58}
u 16bit
10999 10999 Sum over lifetime:
temperature sensor 1, open circuit
Tripping
The following event numbers are counted: {59}
u 16bit
11000 11000 Sum over lifetime:
temperature sensor 2, temperature exceeded
Tripping
The following event numbers are counted: {60},{61}
u 16bit
11001 11001 Sum over lifetime:
temperature sensor 2, temperature exceeded
Interlocked tripping
The following error numbers are counted: {60}, {61}
u 16bit
11002 11002 Sum over lifetime:
temperature sensor 2, short circuit
Tripping
The following event numbers are counted: {62}
u 16bit
11003 11003 Sum over lifetime:
temperature sensor 2, open circuit
Tripping
The following event numbers are counted: {63}
u 16bit
11004 11004 Sum over lifetime:
leakage monitoring 1
Tripping
The following error numbers are counted: {64},{65}
u 16bit
