KWP
Part No. Description Part No. Description
102 Casing 456 Neck ring
135.1 Wear Plate 458 Lantern ring
163 Pressure cover 461 Gland packing
183 Support feet 507 Splash ring
210 Shaft 524 Shaft protection sleeve
230 Impeller 638 Constant level oiler
321.1 Deep groove ball bearing 672 Vent plug
322 Cylindrical roller bearing 906 Impeller cap
330 Bearing bracket 908.01 Hex. bolt / dismantling
344 Bearing bracket lantern 923 Withdrawal nut
360.01 Bearing cover 931 Lock washer
360.02 Bearing end cover 932.01 / .02 Circlip
400.01 - .05 Flat gasket 940.01 / .02 Key
411.01 - .17 Flat gasket 901.01 - .04 Hex. head bolt
412.01 O - ring 902.01 / .02 Stud
421.01 / .02 Oil Seal 903.01 - .11 Plug
452 Stuffing box gland 914.02 / .03 Allen head screw
454 Stuffing box pressure ring 920.01 - .02/.04 Hex. nut - bearing bracket
List of components
