KWP
5.3 Spares
5.3.1 Ordering spare parts.
When ordering spare parts, always please specify the
following data :
Pump type : (KWP in this case)
Part No. :
Works order No.:
The above data are stamped on the data plate fixed on the
pump.
5.3.2 Recommended stock of spares for one
year of operation
5.3.3 Interchangeability of Components.
Within each horizontal line, components with the same number
are interchangeable.
Bearing bracket
Part No. Part Name 35/80 45/120 55/140 65/160d
65-200 80-250 65-315 100-400 150-315 125-500
101 Volute casing 3 4 5 9 10 12
135.1 Wear plate 3 4 5 9 10 12
163 Pressure cover 2 3 4 6 7 8
183 Support foot 3 4 5 7 8 9
210 Shaft 2 2 3 4 4 5
230 Impeller 3 4 5 9 10 12
321.1/.2 Deep groove ball brg. 2P/U 2 2 3 4 4 5
330 Bearing bracket 2 2 3 4 4 5
344 Bearing bracket lantern 2 3 4 5 6 7
452 Stuffing box gland 2 2 3 4 4 5
454 Stuffing box pr.ring 2 2 3 4 4 5
456 Neck ring 2 2 3 4 4 5
458 Lantern ring 2 2 3 4 4 5
461 Stuffing box packing 2 2 3 4 4 5
507 Splash ring 2 2 3 4 4 5
524 Shaft prot.sleeve 2 2 3 4 4 5
906 Impeller cap 2 2 3 4 4 5
Number of pumps installed
Part No. Part Name including stand by pumps
2 - 3 4 - 7 8 & above
135.1 Wear plate 2 3 50%
210 Shaft with keys 1 2 30%
230 Impeller 1 2 30%
454 Stuffing box pressure ring 1 2 30%
456 Neck ring 1 2 30%
458 Lantern ring 1 2 30%
461 Stuffing box packing (4 rings) 4 6 40%
524 Shaft protection sleeve 2 3 50%
321.1/.2 Deep groove ball brg. 2P/U 1 3 50%
412.3 O-rings 4 8 150%
421.1/2 Oil seals (set) 1 3 50%
- Set of gaskets 4 8 150%
7
