14. Slip shaft sleeve 523 with seat ring 475 onto the pump shaft until it abuts against
the shaft shoulder.
7.5.4.2 Packing the gland
UG1258354
l
1
l
2
Ø d
i
Ø d
a
Fig. 20: Dimensions of the packing chamber / Number of packing rings
Table 21: Gland packing chamber
Bearing bracket Gland packing chamber Number of packing
rings
Ød
i
Ød
a
□ l
1
l
2
with
lantern
ring
without
lantern
ring
P03ax 45 65 10 64 8
4
18)
6
P04ax 55 75 10 64 8
4
18)
6
P05ax 70 95 12.5 79 8
4
18)
6
P06x 80 105 12.5 79 10
4
18)
6
P08sx 100 132 16 103 10
4
18)
6
P10ax 120 152 16 103 7
4
18)
6
P12sx 140 172 16 103 7
4
18)
6
Gland packing chamber
18)
For model 4 (see illustration "Available models"): 1 spacer ring and 3 packing rings
7 Servicing/Maintenance
